UV Laser Sculpfun
Sculpfun V5 UV 5W
$3,099
approximate street price
The Sculpfun V5 UV is a 5W 355nm galvo UV laser with dual field lens options (70×70mm for ultra-fine detail; 150×150mm for larger format), an electric Z-axis, and dual-light positioning for accurate material placement. With a 0.0019mm spot and 10,000mm/s speed it handles PCB marking, glass etching, and plastics without the heat damage that limits other laser types.
Full Specifications
| Laser | |
| Type | UV Laser |
| Wavelength | 355 nm |
| Optical Power | 5 W |
| Performance | |
| Work Area | 150 × 150 mm |
| Max Speed | 600,000 mm/min |
| Focus | electric-z |
| Features | |
| Enclosure | No |
| Air Assist (incl.) | No |
| Rotary Compatible | Yes |
| WiFi | Yes |
| Camera | No |
| Physical | |
| Approx. Price | $3,099 |
| Release Year | 2024 |
| Weight | 26.7 kg |
Pros & Cons
What we like
- Dual field lenses included (70mm precision + 150mm standard)
- 0.0019mm spot size for extremely fine detail
- Electric Z-axis for easy height adjustment
- Dual-light positioning for accurate setup
- Compatible with 1,500+ materials per Sculpfun spec
Watch out for
- Premium price for a 5W UV
- No enclosure — safety eyewear required
- Limited to marking/engraving — UV cannot cut materials
Compatible Materials
GlasscrystalceramicplasticpcbWoodAcrylicLeatherAnodized AluminumMetal EngravingPaper
